Baugruppe
AXIAL-PISTON PUMPR902030153
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R909607876 | ROTARY GROUP Stückliste der Baugruppe →L | 1 | ||
| R902016006 | CONTROL Stückliste der Baugruppe →L | 1 | ||
| R902009315 | CONNECTION PLATE Stückliste der Baugruppe →L | 1 | ||
| R909606805 | INTERNAL GEAR PUMP Stückliste der Baugruppe →L | 1 | ||
| R909606715 | CONTROL MODULE Stückliste der Baugruppe →L | 1 | ||
| R902032157 | CONTROL CARTRIDGE Stückliste der Baugruppe →L | 1 | ||
| R902010618 | HOUSING | 1 | ||
| R902114380 | PIVOT PIN | 2 | ||
| 20 | R909154480 | SCREW PLUGD | 1 | |
| R909153371 | SCREW PLUGD | 2 | ||
| R909154478 | SCREW PLUG | 2 | ||
| 28 | R909426700 | NOZZLE | 2 | |
| R913016373 | SLOTTED SPRING PIN | 2 | ||
| R909153364 | SCREW PLUGD | 4 | ||
| R909087913 | SCREW PLUG | 1 | ||
| R902035616 | ECCENTRIC SCREW | 1 | ||
| R909087405 | SEALING NUTD | 1 | ||
| R909831349 | PLUG | 1 | ||
| R902030227 | HYDRAULIC LINE Stückliste der Baugruppe →L | 1 | ||
| R909156497 | NOZZLE | 1 | ||
| 98 | R902095526 | SEAL KIT | 1 |
