Baugruppe
ROTARY GROUPR902034143
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R902033093 | CYLINDER | 1 | ||
| R902033094 | CONTROL PLATE | 1 | ||
| R902028565 | CENTER PIN | 1 | ||
| R902031675 | PISTON | 7 | ||
| R909409994 | WASHER | 1 | ||
| R902130610 | ADJUSTMENT SHIM Stückliste der Baugruppe →L | 1 | ||
| R902028810 | COMPRESSION SPRING | 1 | ||
| 8 | R902000017 | LOCKING PIN | 1 | |
| R909444063 | RETAINING PLATE | 1 | ||
| R902602493 | PAN-HEAD SCREW | 7 |
