Baugruppe
AXIAL-PISTON PUMPR902060677
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R902060684 | ROTARY GROUP Stückliste der Baugruppe →L | 1 | ||
| R902066955 | CONNECTION PLATE, RL Stückliste der Baugruppe →L | 1 | ||
| R909446895 | REGULATOR Stückliste der Baugruppe →L | 1 | ||
| R909600261 | CONTROL Stückliste der Baugruppe →L | 1 | ||
| R902015419 | CONTROL Stückliste der Baugruppe →L | 1 | ||
| R902021367 | SEALING COVER Stückliste der Baugruppe →L | 1 | ||
| R902014973 | BELL HOUSING Stückliste der Baugruppe →L | 1 | ||
| R902224687 | HOLD-DOWN ELEMENT Stückliste der Baugruppe →L | 1 | ||
| R902094196 | HOUSING | 1 | ||
| R902132714 | PIVOT PIN | 4 | ||
| R909449416 | IMPELLER, RIGHT-HAND ROTATION | 1 | ||
| R909921095 | SETSCREW | 2 | ||
| R909153328 | SEALING NUTD | 2 | ||
| R909153364 | SCREW PLUGD | 4 | ||
| R909831387 | SOCKET HEAD CAP SCREW | 4 | ||
| R909831133 | O-RINGD | 1 | ||
| R909153378 | SCREW PLUGD | 2 | ||
| R913016375 | SLOTTED SPRING PIN | 2 | ||
| R909151259 | RETAINING RING | 2 | ||
| R909153371 | SCREW PLUG | 1 | ||
| R902600612 | BLEEDER VALVE | 2 | ||
| R909086482 | O-RING | 1 | ||
| R902014895 | FLANGE | 1 |
