Baugruppe
REGULATORR902075624
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| 1 | R902075626 | CONTROL ELEMENT Stückliste der Baugruppe →L | 1 | |
| R902037603 | CONTROL ELEMENT Stückliste der Baugruppe →L | 1 | ||
| R902080302 | MEASURING PISTON Stückliste der Baugruppe →L | 1 | ||
| R909438013 | CONTROL ELEMENT Stückliste der Baugruppe →L | 1 | ||
| R902081457 | CONTROL HOUSING | 1 | ||
| R909431326 | LOCKING BOLT | 1 | ||
| R909445893 | ANGLE LEVER | 1 | ||
| R909431281 | BEARING BOLT | 1 | ||
| R909431286 | BUSHING | 1 | ||
| R909083053 | SOCKET HEAD CAP SCREW | 5 | ||
| R913009676 | STRAIGHT PIN | 2 | ||
| R909831318 | DOUBLE BREAK-OFF PLUG | 8 | ||
| R909157512 | O-RINGD | 3 | ||
| R902600656 | O-RINGD | 1 | ||
| R909083225 | SCREW PLUG | 1 | ||
| R909083758 | O-RING | 1 | ||
| R909151694 | SCREW PLUG | 1 | ||
| R909153364 | SCREW PLUG | 1 | ||
| R909087248 | RETAINING RING | 1 | ||
| R909083724 | O-RINGD | 1 | ||
| 98 | R902002478 | SEAL KIT | 1 |
