Baugruppe
AXIAL-PISTON PUMPR902088014
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R902108159 | ROTARY GROUP Stückliste der Baugruppe →L | 1 | ||
| R902136631 | CONTROL Stückliste der Baugruppe →L | 1 | ||
| R902039988 | CONNECTION PLATE Stückliste der Baugruppe →L | 1 | ||
| R902029811 | BELL HOUSING Stückliste der Baugruppe →L | 1 | ||
| R902269442 | HOUSING | 1 | ||
| R902114380 | PIVOT PIN | 2 | ||
| R902005089 | SLIDER | 1 | ||
| R909153338 | SCREW PLUGD | 1 | ||
| R909154478 | SCREW PLUGD | 1 | ||
| R909153364 | SCREW PLUGD | 2 | ||
| R909153371 | SCREW PLUGD | 2 | ||
| R909156492 | NOZZLE | 2 | ||
| R913016373 | SLOTTED SPRING PIN | 2 | ||
| R909154589 | O-RINGD | 1 | ||
| 46 | R902039583 | ECCENTRIC SCREW | 1 | |
| 47 | R909153271 | SEALING NUT | 1 | |
| 98 | R902095568 | SEAL KIT | 1 |
