Baugruppe
CONTROLR902088687
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R902088686 | CONTROL PART Stückliste der Baugruppe →L | 1 | ||
| R902088737 | COVER Stückliste der Baugruppe →L | 1 | ||
| R902088622 | COVER PLATE | 1 | ||
| R902101481 | POSITIONING PISTON | 1 | ||
| R902086749 | POSITIONING STUD | 1 | ||
| R902088535 | PISTON | 1 | ||
| R902101482 | SETSCREW | 1 | ||
| R902132472 | CHECK VALVE | 2 | ||
| R909412756 | BUSHING | 2 | ||
| R909083131 | SOCKET HEAD CAP SCREW | 8 | ||
| R909085577 | O-RINGD | 6 | ||
| R909831057 | SOCKET HEAD CAP SCREW | 1 | ||
| R902602841 | STEEL SEALING RINGD | 2 | ||
| R913009666 | STRAIGHT PIN | 2 | ||
| R909831318 | DOUBLE BREAK-OFF PLUG | 1 |
