Baugruppe
CONTROLR902202303
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R902196916 | COVER PLATE, CLOCKWISE ROTATION | 1 | ||
| R902196926 | POSITIONING PISTON | 1 | ||
| R902196925 | POSITIONING STUD | 1 | ||
| R902063825 | SETSCREW | 1 | ||
| R902202298 | ADJUSTMENT SPINDLE | 1 | ||
| R902602036 | DEEP-GROOVE BALL BEARING | 1 | ||
| R913004029 | RETAINING RING | 1 | ||
| R902600667 | O-RINGD | 1 | ||
| R902202305 | COVER Stückliste der Baugruppe →L | 1 | ||
| 23 | R909430627 | PARALLEL KEY | 1 | |
| 24 | R909430630 | CLAMPING DISC | 1 | |
| 25 | R902138392 | HANDWHEEL Stückliste der Baugruppe →L | 1 | |
| 30 | R902149487 | SETSCREW | 1 | |
| 31 | R909411160 | DISC SPRING | 4 | |
| 32 | R902138314 | EXPANSION PIECE | 1 | |
| 33 | R909830246 | CLAMPING LEVER | 1 | |
| R913009667 | STRAIGHT PIN | 2 | ||
| R909083097 | SOCKET HEAD CAP SCREW | 4 | ||
| R902601712 | SCREW PLUG | 1 |
