Baugruppe
AXIAL-PISTON PUMPR902250933
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R902199711 | ROTARY GROUP Stückliste der Baugruppe →L | 1 | ||
| R902008777 | CONTROL Stückliste der Baugruppe →L | 1 | ||
| R902246962 | CONNECTION PLATE Stückliste der Baugruppe →L | 1 | ||
| R909606383 | INTERNAL GEAR PUMP Stückliste der Baugruppe →L | 1 | ||
| R902236122 | CONTROL MODULE Stückliste der Baugruppe →L | 1 | ||
| R902029575 | HOUSING | 1 | ||
| R902132713 | PIVOT PIN | 1 | ||
| R909405732 | POITIONING PIN | 1 | ||
| R909154480 | SCREW PLUGD | 1 | ||
| R909153371 | SCREW PLUGD | 2 | ||
| R909154478 | SCREW PLUGD | 4 | ||
| R909153572 | SCREW PLUG | 1 | ||
| R909831318 | DOUBLE BREAK-OFF PLUG | 2 | ||
| R913016373 | SLOTTED SPRING PIN | 2 | ||
| R909153364 | SCREW PLUGD | 1 | ||
| R909154981 | SETSCREW | 1 | ||
| R909153271 | SEALING NUTD | 1 | ||
| R902215801 | HYDRAULIC LINE Stückliste der Baugruppe →L | 1 | ||
| R902215796 | HYDRAULIC LINE Stückliste der Baugruppe →L | 1 | ||
| 98 | R902095502 | SEAL KIT | 1 |
