Baugruppe
CONTROL PARTR902414673
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R910926601 | VALVE INSERT | 1 | ||
| R910930368 | CONTROL HOUSING | 1 | ||
| R910930294 | SPRING DISK | 1 | ||
| R910930286 | SPRING | 1 | ||
| R902408868 | PRESSURE REDUCING VALVE Stückliste der Baugruppe →L | 1 | ||
| R902430576 | PLUG | 2 | ||
| R909153934 | SOCKET HEAD CAP SCREW | 4 | ||
| R910515574 | O-RING | 2 | ||
| R910518336 | O-RINGD | 4 | ||
| R910930814 | O-RINGD | 2 | ||
| R910927882 | BACKUP RINGD | 2 | ||
| R909831319 | DOUBLE BREAK-OFF PLUG | 1 | ||
| R909153930 | SCREW PLUGD | 1 | ||
| R909831317 | DOUBLE BREAK-OFF PLUG | 1 | ||
| R910921703 | NOZZLE | 1 |
