Baugruppe
BASE UNITR902502115
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| 1 | R910956007 | ROTARY GROUP Stückliste der Baugruppe →L | 1 | |
| 2 | R910910873 | ADJUSTING PIECE Stückliste der Baugruppe →L | 1 | |
| 5 | R902535982 | PUMP HOUSING | 1 | |
| 6 | R902536002 | CONNECTION PLATE | 1 | |
| R910961017 | SWASH PLATE Stückliste der Baugruppe →L | 1 | ||
| 8 | R910998844 | DRIVE SHAFT | 1 | |
| R910939005 | ADJUSTMENT SHIM | 1 | ||
| R910720224 | TAPERED-ROLLER BEARING | 1 | ||
| R910720232 | TAPERED-ROLLER BEARING | 1 | ||
| R910902777 | BEARING SHELL | 2 | ||
| 20 | R910764701 | SHAFT SEALING RINGD | 1 | |
| R910764728 | O-RINGD | 1 | ||
| R913052117 | R-RINGD | 4 | ||
| R910941918 | RETAINING RING | 1 | ||
| R910110272 | SOCKET HEAD CAP SCREW | 4 | ||
| R909153930 | SCREW PLUGD | 2 | ||
| R902601712 | SCREW PLUGD | 1 | ||
| 31 | R909831318 | DOUBLE BREAK-OFF PLUG | 1 | |
| 33 | R902533908 | STRAIGHT PIN | 1 | |
| 43 | R900002645 | SLOTTED SPRING PIN | 1 |
