Baugruppe
CONTROLR909424939
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R909414915 | COVER Stückliste der Baugruppe →L | 1 | ||
| R909414916 | COVER Stückliste der Baugruppe →L | 1 | ||
| R909424941 | SEALING CAP Stückliste der Baugruppe →L | 1 | ||
| R909416837 | COVER PLATE, CLOCKWISE ROTATION | 1 | ||
| R902024644 | SEALD | 1 | ||
| R909425472 | POSITIONING PISTON | 1 | ||
| R909425458 | POSITIONING STUD | 1 | ||
| R909414864 | SPRING DISK | 1 | ||
| R909414865 | SPRING DISK | 1 | ||
| R909424406 | RING | 1 | ||
| R909414907 | COMPRESSION SPRING | 1 | ||
| R909414908 | COMPRESSION SPRING | 1 | ||
| R909408958 | SETSCREW | 1 | ||
| R909083142 | SOCKET HEAD CAP SCREW | 7 | ||
| R909083129 | SOCKET HEAD CAP SCREW | 1 | ||
| R913009666 | STRAIGHT PIN | 2 | ||
| R909156494 | NOZZLE | 1 | ||
| R909156706 | R-RINGD | 1 | ||
| R909156707 | ROD SEALD | 1 | ||
| R909831319 | DOUBLE BREAK-OFF PLUG | 5 | ||
| R909831318 | DOUBLE BREAK-OFF PLUG | 1 | ||
| R909083489 | SETSCREW | 1 | ||
| R909424407 | BACKUP RING | 1 |
