Baugruppe
CONTROLR909428896
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R909429463 | CONTROL MODULE Stückliste der Baugruppe →L | 1 | ||
| R909428917 | COVER Stückliste der Baugruppe →L | 1 | ||
| R909431277 | CONTROL HOUSING | 1 | ||
| R909431753 | POSITIONING PISTON | 1 | ||
| R909415155 | SWIVEL FORK | 1 | ||
| R909431220 | CENTERING BOLT | 1 | ||
| R909650531 | SEALD | 1 | ||
| R909411422 | COMPRESSION SPRING | 1 | ||
| R913007909 | STRAIGHT PIN | 2 | ||
| R909083100 | SOCKET HEAD CAP SCREW | 4 | ||
| R909083087 | SOCKET HEAD CAP SCREW | 8 | ||
| R909156479 | R-RINGD | 1 | ||
| R902602854 | STEEL SEALING RINGD | 1 | ||
| R909083349 | RETAINING RING | 1 | ||
| R909831319 | DOUBLE BREAK-OFF PLUG | 2 | ||
| R909831320 | DOUBLE BREAK-OFF PLUG | 1 | ||
| R909153371 | SCREW PLUGD | 2 |
