Baugruppe
CONTROLR909448137
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R909610879 | COVER Stückliste der Baugruppe →L | 2 | ||
| R909448136 | CONTROL MODULE Stückliste der Baugruppe →L | 1 | ||
| R909652002 | CONTROL HOUSING | 1 | ||
| R909650531 | SEALD | 1 | ||
| R909445909 | POSITIONING PISTON | 2 | ||
| R909425459 | POSITIONING STUD | 2 | ||
| R909921685 | SPRING DISK | 2 | ||
| R909425746 | COMPRESSION SPRING | 2 | ||
| R909449216 | PISTON | 2 | ||
| R909445015 | SETSCREW | 2 | ||
| R909083708 | HEXAGON SCREW | 2 | ||
| R902602841 | STEEL SEALING RINGD | 4 | ||
| R909083093 | SOCKET HEAD CAP SCREW | 8 | ||
| R909083100 | SOCKET HEAD CAP SCREW | 4 | ||
| R913007909 | STRAIGHT PIN | 2 | ||
| R909831318 | DOUBLE BREAK-OFF PLUG | 3 | ||
| R909831319 | DOUBLE BREAK-OFF PLUG | 2 | ||
| R909153371 | SCREW PLUGD | 2 |
