Baugruppe
CONTROLR910811254
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R910806471 | COVER Stückliste der Baugruppe →L | 1 | ||
| R910806498 | ADJUSTING PIECE Stückliste der Baugruppe →L | 1 | ||
| 50 | R910803618 | COVER PLATE | 1 | |
| 50 | R910945129 | O-RINGD | 1 | |
| 50 | R910808873 | POSITIONING PISTON | 1 | |
| 50 | R902413798 | POSITIONING STUD | 1 | |
| 52 | R910595403 | SCREW PLUG | 1 | |
| 53 | R910808989 | SETSCREW | 1 | |
| 62 | R910110043 | SOCKET HEAD CAP SCREW | 6 | |
| 62 | R910100838 | SPRING LOCK WASHER | 8 | |
| 62 | R910514179 | STRAIGHT PIN | 2 | |
| 63 | R909831319 | DOUBLE BREAK-OFF PLUG | 2 | |
| 63 | R909831320 | DOUBLE BREAK-OFF PLUG | 1 | |
| 63 | R910120901 | SOCKET HEAD CAP SCREW | 2 | |
| 63 | R910516481 | O-RINGD | 1 | |
| 63 | R909153364 | SCREW PLUGD | 2 | |
| 64 | R909151692 | SCREW PLUGD | 1 | |
| 64 | R909151694 | SCREW PLUGD | 1 | |
| 64 | R910843121 | HANDWHEEL | 1 | |
| 64 | R910100986 | SETSCREW | 1 | |
| 66 | R909153816 | SCREW PLUGD | 1 |
