Baugruppe
ADJUSTING PIECER910984244
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R910901133 | ADJUSTING PISTON | 1 | ||
| R902557761 | PRESSURE PISTON | 2 | ||
| R902519614 | STOP SCREW | 1 | ||
| R910971674 | PISTON GUIDE | 2 | ||
| R910945721 | PISTON HOUSING | 2 | ||
| R910187704 | SETSCREW | 1 | ||
| R910923831 | R-RINGD | 2 | ||
| R902650323 | R-RINGD | 2 | ||
| R910513482 | O-RINGD | 2 | ||
| R910911739 | O-RINGD | 4 | ||
| R909153815 | SCREW PLUG | 2 | ||
| R902519537 | STUD BOLT | 2 | ||
| R910127116 | HEXAGON NUT | 2 | ||
| R910902827 | NUT | 2 | ||
| R910604976 | SOCKET HEAD CAP SCREW | 8 | ||
| R910951021 | COMPRESSION SPRING | 1 | ||
| R910902828 | CAP NUT | 2 | ||
| R902519613 | STOP SCREW | 1 | ||
| R910978692 | PLUG | 2 | ||
| R902650982 | DUMMYD | 2 | ||
| R910977071 | O-RINGD | 2 | ||
| R909153364 | SCREW PLUGD | 8 | ||
| R910987526 | SCREW PLUG | 1 | ||
| R910926851 | SNAP RING | 2 |
