Einheit · AXIAL-PISTON MOTOR
AA10FD85/52W-VRZ81B123-S1371R902417749
Axialkolbenmotor Bosch Rexroth Baureihe A10FD, Typschlüssel AA10FD85/52W-VRZ81B123-S1371, Materialnummer R902417749.
- Nummer
- R902417749
- Typschlüssel
- AA10FD85/52W-VRZ81B123-S1371
- Gruppe
- A10FD 85
- Ausgabe
- 08/2018
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R902417750 | BASE UNIT Stückliste der Baugruppe →L | 1 | ||
| R902491400 | CONNECTION PLATE Stückliste der Baugruppe →L | 1 | ||
| R971060477 | PRESSURE RELIEF VALVE | 1 | ||
| R910109215 | SOCKET HEAD CAP SCREW | 2 | ||
| R902603191 | SEAL SCREW | 3 | ||
| R902602015 | SEAL SCREW | 2 | ||
| R902416144 | REFERENCE PLATE | 1 | ||
| R902544506 | PROTECTIVE TUBE | 1 | ||
| 70 | R902603191 | SEAL SCREW | 2 | |
| 71 | R902603191 | SEAL SCREW | 1 | |
| 72 | R902602015 | SEAL SCREW | 1 | |
| 73 | R902602015 | SEAL SCREW | 1 | |
| 75 | R909830326 | NAMEPLATE | 1 |
