Einheit · AXIAL-PISTON PUMP
A8VO107LR3CH2/60R1-NZG05K07R909427752
Axialkolbenpumpe Bosch Rexroth Baureihe A8VO, Typschlüssel A8VO107LR3CH2/60R1-NZG05K07, Materialnummer R909427752.
- Nummer
- R909427752
- Typschlüssel
- A8VO107LR3CH2/60R1-NZG05K07
- Gruppe
- A8VO 107
- Ausgabe
- 06/2020
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R909427909 | AXIAL-PISTON PUMP Stückliste der Baugruppe →L | 1 | ||
| R909427442 | CONTROL Stückliste der Baugruppe →L | 1 | ||
| R902119595 | TOOTHED WHEEL | 1 | ||
| R909425539 | FLANGE | 1 | ||
| R909085366 | O-RINGD | 1 | ||
| R909085479 | DEEP-GROOVE BALL BEARING | 1 | ||
| R909150669 | DEEP-GROOVE BALL BEARING | 1 | ||
| R909083086 | SOCKET HEAD CAP SCREW | 4 | ||
| R909083225 | SCREW PLUG | 2 | ||
| R909083758 | O-RINGD | 2 | ||
| R909152426 | SEALING NUTD | 1 | ||
| R909083500 | SETSCREW | 1 | ||
| R909083128 | SOCKET HEAD CAP SCREW | 4 | ||
| R913045131 | O-RINGD | 1 | ||
| R909433159 | HYDRAULIC LINE Stückliste der Baugruppe →L | 1 | ||
| R909438762 | HYDRAULIC LINE Stückliste der Baugruppe →L | 1 |
