Einheit · CONTROL
V A7V 1000 LV FERNGEST.R910803487
Regler Bosch Rexroth Baureihe A7V, Typschlüssel VA7V1000LVFERNGEST., Materialnummer R910803487.
- Nummer
- R910803487
- Typschlüssel
- V A7V 1000 LV FERNGEST.
- Gruppe
- A7V 1000
- Ausgabe
- 06/2020
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R910850055 | COVER Stückliste der Baugruppe →L | 1 | ||
| R910590681 | CONTROL PART Stückliste der Baugruppe →L | 1 | ||
| R910809314 | CONNECTING PIECE | 1 | ||
| R910805556 | COVER Stückliste der Baugruppe →L | 1 | ||
| R910814008 | COVER PLATE | 1 | ||
| R910544752 | O-RINGD | 1 | ||
| R910841803 | POSITIONING PISTON | 1 | ||
| R902414363 | POSITIONING STUD | 1 | ||
| R910590304 | GUIDE ROD | 1 | ||
| R910806749 | SPRING BUSH | 1 | ||
| R910806757 | SPRING BUSH | 1 | ||
| R910590207 | RING | 1 | ||
| R910578363 | THROTTLE SCREW | 1 | ||
| R910839299 | THROTTLE DISC | 1 | ||
| R910414751 | SOCKET HEAD CAP SCREW | 10 | ||
| R910100846 | SPRING LOCK WASHER | 12 | ||
| R910514179 | STRAIGHT PIN | 2 | ||
| R910672009 | SLOTTED SPRING PIN | 1 | ||
| R902533060 | SETSCREW | 1 | ||
| R910579947 | SOCKET HEAD CAP SCREW | 2 | ||
| R909151692 | SCREW PLUGD | 6 | ||
| R909151979 | SCREW PLUGD | 2 | ||
| R909153815 | SCREW PLUGD | 1 | ||
| R909154024 | SCREW PLUGD | 2 | ||
| R910803383 | SETSCREW | 1 | ||
| R909153816 | SCREW PLUGD | 1 |
