Einheit · AXIAL-PISTON PUMP
A4V56HW1.0L0X1O1O-SR909428990
Axialkolbenpumpe Bosch Rexroth Baureihe A4V, Typschlüssel A4V56HW1.0L0X1O1O-S, Materialnummer R909428990.
- Nummer
- R909428990
- Typschlüssel
- A4V56HW1.0L0X1O1O-S
- Gruppe
- A4V 56
- Ausgabe
- 07/2020
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R909410721 | ROTARY GROUP Stückliste der Baugruppe →L | 1 | ||
| R909414468 | CONTROL Stückliste der Baugruppe →L | 1 | ||
| R909078290 | CONNECTION PLATE Stückliste der Baugruppe →L | 1 | ||
| R909404646 | INTERNAL GEAR PUMP Stückliste der Baugruppe →L | 1 | ||
| R909071574 | CONTROL UNIT Stückliste der Baugruppe →L | 1 | ||
| R909428681 | BELL HOUSING Stückliste der Baugruppe →L | 1 | ||
| R909405945 | HOUSING | 1 | ||
| R909074129 | FLANGE | 1 | ||
| R909414043 | ANTI-TWIST LOCK | 1 | ||
| R909414044 | ANTI-TWIST LOCK | 1 | ||
| R909154981 | SETSCREW | 1 | ||
| R909400345 | PIPE Stückliste der Baugruppe →L | 1 | ||
| R909425992 | SLIDER | 1 | ||
| R909405732 | POITIONING PIN | 1 | ||
| R909151694 | SCREW PLUGD | 1 | ||
| R909151692 | SCREW PLUGD | 5 | ||
| R909084400 | SCREW PLUG | 1 | ||
| R909153572 | SCREW PLUG | 1 | ||
| R909083761 | O-RINGD | 1 | ||
| R909083825 | O-RINGD | 1 | ||
| R909153271 | SEALING NUTD | 1 | ||
| R909831318 | DOUBLE BREAK-OFF PLUG | 1 | ||
| R909156492 | NOZZLE | 2 | ||
| R909153817 | SOCKET HEAD CAP SCREW | 4 |
