Einheit · AXIAL-PISTON PUMP
A8VO28SR3Z/60R3-NZG05K011R909437831
Axialkolbenpumpe Bosch Rexroth Baureihe A8VO, Typschlüssel A8VO28SR3Z/60R3-NZG05K011, Materialnummer R909437831.
- Nummer
- R909437831
- Typschlüssel
- A8VO28SR3Z/60R3-NZG05K011
- Gruppe
- A8VO 28
- Ausgabe
- 05/2018
| Pos. | Nummer | Bezeichnung | Menge | Zur Anfrage |
|---|---|---|---|---|
| R909437832 | CONTROL Stückliste der Baugruppe →L | 1 | ||
| R909441545 | ROTARY GROUP Stückliste der Baugruppe →L | 1 | ||
| R909441546 | ROTARY GROUP Stückliste der Baugruppe →L | 1 | ||
| R909441547 | ROTARY GROUP Stückliste der Baugruppe →L | 1 | ||
| R909436880 | GEAR HOUSING | 1 | ||
| R909436883 | ROTARY GROUP HOUSING | 1 | ||
| R909439053 | LOCKING RING | 1 | ||
| R909650392 | SEALD | 1 | ||
| R909443221 | TOOTHED WHEEL | 1 | ||
| R909426804 | VALVE SPOOL | 1 | ||
| R909403718 | COMPRESSION SPRING | 1 | ||
| R909409509 | SCREW PLUG | 1 | ||
| R909080515 | WASHER | 2 | ||
| R909083412 | RETAINING RING | 2 | ||
| R909152835 | SHAFT SEALING RINGD | 1 | ||
| R909083788 | O-RINGD | 1 | ||
| R909153891 | SCREW PLUGD | 1 | ||
| R909151979 | SCREW PLUGD | 2 | ||
| R913009667 | STRAIGHT PIN | 2 | ||
| R909085446 | DEEP-GROOVE BALL BEARING | 2 | ||
| — | O-RINGD | 1 | ||
| R909083061 | SOCKET HEAD CAP SCREW | 13 | ||
| R909083760 | O-RINGD | 1 | ||
| — | DOUBLE BREAK-OFF PLUG | 1 | ||
| R909083060 | SOCKET HEAD CAP SCREW | 2 | ||
| 2916010114 | WASHER | 2 | ||
| R909087188 | SUPPORTING DISCD | 1 | ||
| 98 | R902166275 | SEAL KIT | 1 |
